Tsav Bobbin CNC Chev Winding Tshuab
Tsav Bobbin CNC Coil Winding Machin muaj tus lej ua haujlwm, tiv thaiv kev hloov pauv
Hauj lwm lawm
Npe ：GW-92008 Tsav Bobbin CNC Chev Winding Tshuab
KEV KAWM:
Tswj System | CNC 6 Axis AC servo motor synchronizing tswj | Twisting Ntev | 250 hli (Max) |
Cia Txoj Kev | Windows interface PC nrog USB txuas& DVD ROM | Twisting Number | Yeem muaj nuj nqi |
Winding Spindle | 8 ntxaiv, ntxaiv nrug ： 55mm | Hwj chim Source | 220V ± 10%, ib theem |
Spindle Lub | 360 °/tig -teeb chav tsev 0.1 ° | Kev Siv Hluav Taws Xob | 3 KWV |
Nres Qhov Tseeb | ±0.1° | Cov Khoom Siv Cua | 4-6kgf/cm² |
Nozzle Txav deb | X Axis 100mm, txav chaw 0.001mm Y Axis 75mm, txav chaw 0.001mm Z Axis 65mm, txav chaw 0.001mm | Tshuab Dimension | 110 × 130 × 155 hli |
Hlau Loj | 0.02 hli-0.3 hli | Net Nyhav | 540kg ua |
Winding Dav | 85 hli (Max) | Ntim Ntim | 124 × 124 × 166 hli |
Muab ceev | 150 tig/Min (Max) | Nyhav Nyhav | 650kgs ua |
Wrapping Angle | 0° 90° 120° | Winding Ceev | 18000RPM (Max) |
FEATURES:
CNC 6 Axis servo lub cev muaj zog kis kab mob
Tsav Bobbin CNC Coil Winding Machin muaj tus lej ua haujlwm, tiv thaiv kev hloov pauv
Tsav Bobbin CNC Coil Winding Tshuab muaj qhov tshwj xeeb winding jig tsim, hloov pauv yooj yim
Tsav Bobbin CNC Coil Winding Tshuab muaj cov qauv yooj yim, yooj yim rau kev saib xyuas
Kev tswj nruj nruj
Cov khoom siv hlau sib txuas, tsis muaj cov hlau seem tawm
Cov lus qib siab hais kom kho qhov program nrog 15 kov vaj huam sib luag
Nws pib thauj khoom& tshem tawm kev ua haujlwm (Kev xaiv)
Cov xov hlau zoo ua haujlwm (Optiona)
Pneumatic cutter device (Tsis teb los tau)
ADVANTAGES:
Tsav Bobbin CNC Coil Winding Machin kom txuag tau lub zog.
cov neeg ua haujlwm hauv rhiav tuaj yeem ua tiav kev ua haujlwm tom qab kev qhia yooj yim, tib neeg ntau dua.
Raws li cov tswv yim ntawm cov txheej txheem sib txawv, tuaj yeem raug mob nyob ib puag ncig ntau yam sib txawv ntawm cov cua hauv tib lub tshuab, ib tus neeg' lub zog ua haujlwm tuaj yeem ua tiav kev ua haujlwm ntau dua kaum ob tus neeg yav dhau los, tsim khoom thiab ua haujlwm tau zoo yog txhim kho
Thiab lub tshuab tsis siv neeg tuaj yeem txuas ntxiv ua haujlwm, kev ua haujlwm tau zoo dua qub, thiab txo tus nqi ntawm kev lag luam.
Tsis siv neeg tshuab winding kom txuag tau lub zog.
Cov neeg ua haujlwm hauv Rhiav tuaj yeem ua tiav kev ua haujlwm tom qab kev qhia yooj yim, tib neeg ntau dua.
KHOOM:
DAIM NTAWV THOV:
Tsis Siv Neeg Coil winding Machine tau siv rau qhov cua tshuab me me EI hloov pauv, teeb liab hloov pauv, inductors, lim choke coil, xa tawm, cov neeg tiv tauj tam sim no, lub tog raj kheej, cov xaim hluav taws xob, xov tooj cua ntxaiv hloov pauv. Nws tuaj yeem ua kom tiav cov coils yam tsis muaj ib tus neeg teb xov tooj tau txais tag nrho.
DAIM NTAWV THOV KEV KAWM:
CUSTOMER CUSTOMER rau OPERATE WINDING MACHNE:
1.Txhua yam kev pabcuam kws tshaj lij nrog 10 xyoo kev paub tau txais kev qhia tshwj xeeb thev naus laus zis, leej twg tuaj yeem daws nrog ntau yam teeb meem tawg.
2.Qhia tus neeg siv kom raug thiab yuav ua li cas thiaj tswj tau cov khoom.
Muab kev sab laj pub dawb txog kev tsim cov txheej txheem thev naus laus zis ntawm cov khoom siv hluav taws xob.
3. Txhawm rau lav lub tshuab siv ib txwm muaj, peb' d muaj kev qhia paub yuav ua haujlwm li cas, siv thiab tswj hwm peb cov khoom los ntawm phau ntawv Askiv, video, qhia hauv kab.
Ntim:
Ntim Cov Khoom: Thawv/Cov ntoo nrog ua npuas dej sab hauv.
1.General pob (Ntawv thooj ntawv lossis lub hnab yas): Rau qhov me me euipped qhov rau Toroidal Transformer Winding Tshuab, Ntim nws nrog daim ntawv thiab pob ntawv kom lav tau tsis tawg thaum thauj.
2.Wooden cov ntaub ntawv pob: Rau qhov loj dua Toroidal Winding tshuab, peb muaj tus kws tshaj lij tshwj xeeb uas yog tus kws ntoo, uas yuav ua rau rooj ntoo kom raug nrog tuab tuab, ntom, ntev. Tus xub xub -cim rau ntawm rooj ntoo sab nrauv. Cov khoom tsis zoo yuav muab tso rau hauv rooj ntoo kom tiv thaiv kev tawg thiab poob siab.
OPTIONAL ACCESSORIES
TSIS YOG | Yam khoom/Specification | ZOO | UNIT |
1 | maub los | 1 | PIECE |
2 | winding lub cev muaj zog | 1 | PIECE |
3 | Tsav tsheb | 1 | PIECE |
4 | optical fiber ntau sensor | 1 | PIECE |
5 | B2-2.0 Nti shuttle | 1 | PIECE |
6 | 4 ntiv tes thiab 6 ntiv tes thauj (pib ntawm tshuab qauv) | 1 | PIECE |
7 | shuttle qhia log | 1 | PIECE |
8 | lub taub hau teeb | 1 | PIECE |
9 | ntsuab puag ncig siv (tuaj yeem xa ib qho dawb hauv txiv kab ntxwv) | 1 | M |
10 | iav puab siv | 1 | Siv |
HOOBKAS:
Peb-GREWIN INDUSTRIAL GROUP yog tus kws tshaj lij hauv tshuab tshuab kab rau 28Years. Peb Grewin muaj ISO9001: 2015, CE pom zoo, Tshuab' Patents,&"; cov tuam txhab thev naus laus zis siab &" los ntawm tsoomfwv.
